Periscope Gen 2

THE MIC FOR
EVERYTHING

Broadcast-ready choir & instrument sound

Periscope Gen 2

THE MIC FOR
EVERYTHING

Broadcast-ready choir & instrument sound

Flexibility Without
Compromise

The Earthworks Audio Periscope microphone has been renowned for its versatility in capturing a wide range of sound sources, from solo instruments to ensembles and choirs. Now, the P30 Gen 2 improves on all aspects of the original.

Tight pattern and full-range sound

Brian Speiser, FOH ENGINEER

The Best Made Better

Earthworks Gen 2 technology ensures that the C30 Gen 2’s supercardioid polar pattern is consistent across the entire frequency range, capturing natural, lifelike sound for all choir members in the entire front hemisphere, with highly effective rejection of unwanted sounds across the rear.

The Best Made Better

Earthworks Gen 2 technology ensures that the P30 Gen 2’s supercardioid polar pattern is consistent across the entire frequency range, capturing natural, lifelike sound for all choir members in the entire front hemisphere, with highly effective rejection of unwanted sounds across the rear.

No Pain In The Neck

The Periscope’s design makes low-profile instrument and choir miking easy by letting you aim the microphone’s capsule at the source while keeping the body inline with the stand. You can capture any sound however you want with the P30 Gen 2.

Made For Your Needs

The attached 30’ (9 meter) Canare Star Quad microphone cable provides enhanced immunity to RF interference and resistance to twisting from temperature fluctuations. Plus, the C30 Gen 2 is available in black and white to best fit your space.

SPECIFICATIONS

Microphone Type
Pre-Polarized Condenser

Polar Pattern
Supercardioid

Diaphragm Size
10mm

Frequency Response
20 Hz – 25 kHz

1 kHz Sensitivity
-35 dBV/Pa (18 mV/Pa)

High Frequency Cutoff
—

A-Weighted Self-Noise
20 dBA

Maximum SPL (3% THD)
141 dB SPL

Minimum Load Impedance
1 kΩ

48V Phantom Power (P48), 6 mA
Construction
Anodized aluminum body, machined stainless steel tip

Dimensions
L × W: 7 × 0.86 inches (80 × 21.84 mm)

Weight
0.22 lbs (100 g)

Color
Black

  • MC1 Microphone Clip
  • SRW3 Foam Windscreen

POLAR PATTERN

Without Windscreen

With Windscreen

FREQUENCY RESPONSE
